This structural detail shows a concrete pipe trench passing below a foundation wall, featuring front and side elevation views. The assembly incorporates tamped sand bedding directly around the pipe with compacted backfill above, maintaining a minimum twenty-one inches clear width and specific clearances for the pipe outer diameter. A two-inch clearance is detailed between the pipe and sleeve. The concrete foundation and footing profiles include dimensional constraints relative to the pipe diameter and positioning.
