An HSS member connects to the primary building framing at a gridline, integrating insulated metal panels and infill framing. A bent plate links the structural steel girder and floor beam assembly to the wall framing with a three-quarter-inch gap. The insulated metal panel system attaches across delegated infill studs supported by structural members. A back draft damper is positioned below the wall assembly per mechanical requirements. Gridline markers establish spatial alignment for the framing and exterior wall facade.
GL GL METAL DECK RE: PLAN B/ DECK RE: PLAN T/WALL RE: ARCH INFILL STUD RE: ARCH (DELEGATED) HSS RE: PLAN BENT PL SIM ARCH RE: RE: ARCH GAP 3/4" BEAM RE PLAN GIRDER RE PLAN INSULATED METAL PANEL, TYP 1 S-61305 BACK DRAFT DAMPER PER MECHANICAL BACK DRAFT DAMPER PER MECHANICAL
