A channel beam connects to the face of a hollow structural section column using a bolted connection sized per the typical schedule. The channel supports a concrete slab over metal deck, with slab thickness, deck size, and gauge determined by project notes. Steel studs are positioned above and below the beam connection point, with specific stud requirements referenced in the steel stud sheets and details.
