Wide-flange beams connect to a hollow structural section column using shear tabs welded to the column face and bolted to the beam web. A one-half inch plate caps the column on four sides with typical welds as specified. Top of steel elevations are referenced per plan for multi-sided framing configurations.
4 SIDES 1/2" TYP. PL 1/2 T/STEEL RE: PLAN T/STEEL RE: PLAN CL TYP A B PLAN AT (4) SIDED CONN. PLAN AT (2) OR (3) SIDED CONN. SECTION
