The drawing illustrates structural steel beam-to-column moment connections presented in elevation, section, and plan views. Key components include wide-flange columns and beams, continuity plates with specified thicknesses, complete joint penetration welds, and erection bolts. The assembly transfers moment forces between the framing members and the column web.
Text on the drawing
PL THICKNESS t1 = 1 8 " + tw OF BM, TYP. 2 12 " TYP. 1 1 2 " TYP. 'X' 'X' k, TYP. 5" 5" 3" TYP. t - 1 16 1 SLOPING CONTINUITY PL MAY BE USED WHEN NO BEAMS ARE MOMENT CONNECTED TO THE COL. WEB AND X≤3" ERECTION BOLTS, TYP. PL THICKNESS t2 = 1 4 " + tf OF LARGEST BM FLANGE, TYP. PLAN A-A d = t + t + 1" f w PL THICKNESS t2 = 1 4 " + tf OF LARGEST BM FLANGE MATCH COL. FLANGE, TYP. PL THICKNESS t1 = 1 4 " + tw OF BM. CONTINUE PL TO BOT. FLANGE CONTINUITY PL IF X≥d/4. NOTCH AND WELD PL SIM. TO DET. X/X (AT MOMENT CONNECTED BEAMS TO COLUMN WEB) WF COL. ELEVATION B-B SECTION C-C t / 2 1 t / 2 1 C C B B A A B B C C t / 2 1 t / 2 1 t - 1 16 1 t / 2 t / 2 T&B FLANGE PL'S, TYP. T&B FLANGE PL TYP. DO NOT WELD IN CORNERS CJP TYP. TYP. 4" RETS T&B, TYP. CJP TYP. 4" RETS T&B, TYP. TYP.
