Structural · S-V4ZFS

Window Opening Framing Support at Side Entry

Materials

Concrete Steel

Elements

Columns Beams Windows Roofs Floors / Slabs Expansion / Control Joints Entrances Anchors / Embeds Roof / Floor Openings

Connections

Base Plate / Anchorage Embed Plate Timber / Mass-Timber Connection

About this detail

Framing support for a window opening consists of hollow structural section members anchored to an existing concrete slab on grade. The vertical framing consists of HSS6x6x3/8 columns supporting an HSS9x6x3/8 header, with an adjacent plan view detailing a 1 1/4-inch base plate secured by four 1/2-inch diameter by 3 1/4-inch Simpson Titen HD embed anchors. Fillet welds of 1/4-inch size are specified on three sides at the base connection. The elevation indicates a maximum span of 13'-0" to the left side supported by the HSS column and an 11'-6" maximum clear opening width.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
