Stringer steel beams frame into a broken back ridge beam utilizing four-bolt connection plates at the web. A continuous one-quarter-inch bent plate sits above the ridge beam and supports the metal roof deck. A three-sixteenth-inch fillet weld with two-to-twelve spacing connects typically to the bent plate.
MTL ROOF DECK 1/4" BENT PL x CONT S301 A1 STL BM BROKEN BACK RIDGE BM 3/16 2-12 TYP TO BENT PL
