Structural · S-V3FHG

Wide Flange Beam Overrun at HSS Column Connection

Materials

Steel

Elements

Columns

Connections

HSS Connection Welded Connection

About this detail

A wide flange steel beam bears onto a hollow structural section column capped with a one-inch steel cap plate welded with complete joint penetration welds. Web stiffeners are welded near side and far side to the column, and continuity plates are provided within the beam-column joint. A 5/16-inch fillet weld secures the cap plate to the beam flange where indicated.
