Wood truss top chords are joined using a continuous steel plate secured with chord plate screws alongside a welded and bolted splice plate. Full depth blocking is installed beyond the splice with six-inch spacing, including notched blocks accommodating the bolts. Block screws secure the blocking members in place.
4x BLK CONT. STL PLATE NOTCH BLOCK AT BOLTS CHORD PLATE SPLICE NOTES: 1. SEE DETAIL 5 FOR INFORMATION NOT NOTED CHORD PLATE SCREWS BLOCK SCREWS 6" FULL DEPTH BLOCKING BEYOND WELDED & BOLTED SPLICE PLATE
