Steel stair stringer bent connection utilizing complete joint penetration welds and supporting channel profiles sized per plan. The assembly connects steel stair stringers sized per structural plans with a complete joint penetration weld at the bent junction. Channel profiles sized per plan are welded to the stringer assembly with quarter-inch fillet welds as indicated by standard weld symbols.
CJP CHANNEL SEE PLAN CJP STRINGER SEE PLAN CHANNEL SEE PLAN 1/4 1/4 A B STRINGER SEE PLAN
