Steel beams connect to the flange of a structural steel column using a welded shear tab. The shear tab is welded to the column flange with a fillet weld sized per schedule 6/S1.04 plus one-sixteenth of an inch. The beam web bolts to the single plate shear tab with a first row of bolts sized per note two and a matching second row of additional bolts.
BEAM TO COLUMN FLANGE C SHOWN ON PLAN THUS: SHEAR TAB SEE NOTE 2 TOP OF STEEL SCHED 6/S1.04 WELD + 1/16 NUMBER AND SIZE OF BOLTS IN 1ST ROW SEE NOTE 2 NUMBER OF ADDITIONAL BOLTS IN 2ND ROW TO MATCH 1ST ROW
