These details show structural kicker brace connections framing to a metal deck, oriented both perpendicular and parallel to the deck flutes. An L76x76x6.4 angle brace connects to a 102x102x6.4 by 450 long plate secured with two nineteen millimeter diameter expansion anchors centered on the deck flutes with a one hundred fifteen millimeter embedment. Fillet welds join the components as indicated by standard weld symbols, with plate details positioned at equal spacings relative to the metal deck support.
2 U.N.O 1 102x102x6.4 x450 W/ (2) 19 DIA EXPANSION ANCHORS CENTERED ON DECK FLUTES - EMBED 115 L76x76x6.4 BRACE U.N.O METAL DECK 6 2 U.N.O 1 102x102x6.4 x450 W/ (2) 19 DIA EXPANSION ANCHORS CENTERED ON DECK FLUTES - EMBED 115 L76x76x6.4 BRACE U.N.O METAL DECK 6 TYP 40 KICKER CONNECTION PERP. TO DECK FLUTES KICKER CONNECTION PARALLEL TO DECK FLUTES EQ EQ
