This structural plan detail outlines the joint layout and reinforcement requirements for a concrete dock leveler pit. Two number 5 by five-foot corner bars are placed typically at the slab re-entrant corners. Control joints and perimeter joints frame the pit perimeter as sized per plan. Dimensions are referenced to the main structural plan.
