The interface between curtain wall number CW01 and a brick veneer wall assembly. A sheet metal flashing extends beneath the brick course, draining to the exterior past a line of sealant A. The dimension from the face of the brick to the face of the mullion is set at zero feet, three and three-eighths inches.
CURTAINWALL # CW01 F.O. BRICK DIM POINT F.O. MULLION 0'-0 3/8" SHEET METAL FLASHING SEALANT A
