Pile Cap Foundation Plans PC8Y and PC8Z

Elements

About this detail

These structural pile cap plans detail the dimensions and pile layouts for footings PC8Y and PC8Z supported by typical 1'-6" diameter piles. Footing PC8Y measures 18'-0" by 13'-0" with typical column centerlines aligned as noted, while PC8Z measures 19'-0" by 19'-0". Both pile caps include reinforcing bar layouts designated as long and short directions with dimensioned spacing.
