A reinforced concrete pile cap supports a cast-in-place concrete slab and a concrete masonry unit wall above. The concrete slab features standard reinforcing detailed per plan with specified development length. The foundation is wrapped with a waterproof membrane and exterior insulation as detailed on architectural drawings. Pile cap reinforcing is detailed on sheet S-MB-5.11.
T.O MAIN FLOOR MB-A CMU WALL SEE ARCH FOR LOCATIONS, TYP SEE PILE CAP REINF, S-MB-5.11 SEE REINF, PLAN INSULATION SEE ARCH, TYP WATERPROOF MEMBRANE SEE ARCH, TYP ld
