A hollow structural section column is reinforced with stiffener plates on each side sized per structural notes. A column cap plate and base plate connect to the assembly with three-sixteenths inch fillet welds. The HSS column size is specified per plan.
BASE PLATE - SEE DETAIL --/S--- COLUMN CAP PLATE - SEE DETAIL --/S--- STIFFENER PLATE EACH SIDE - SEE STRUCTURAL NOTES HSS COLUMN - SEE PLAN 3/16
