This structural detail defines the slab edge condition at a supporting steel beam with a light gauge metal pour stop. The distance from the beam centerline to the slab edge is limited to a maximum of six inches unless an alternate detail is utilized. Stairs, miscellaneous steel, and other miscellaneous items are prohibited from being attached directly to pour stops. Undimensioned slab edges default to a six-inch offset from the beam centerline.
1. DO NOT ATTACH STAIRS, MISC STEEL OR OTHER ITEMS TO POUR STOPS, USE DETAIL 'B' 2. DIMENSION FROM BEAM CL TO SLAB EDGE SHALL NOT EXCEED 6". USE DETAIL 'B' WHEN GREATER THAN 6". 3. WHERE NO DIMENSION FROM BEAM CL TO SLAB IS SHOWN ON PLAN, USE 6". LIGHT GAGE POUR STOP A NOTES:
