A collector plate connects across the column line with a bolted shear tab and a five-sixteenth-inch typical fillet weld to the structural steel column. The framing beam connects to the column flange using a one-and-one-half-inch thick tab plate and high-strength bolts sized per reference detail 1B/s-522. Additional collector plate connections to the column are detailed per reference 2/s-816 at Level 2 top of steel.
(PLAN SYMBOL) NOTE: SEE DETAIL 1B/s-522 FOR INFO NOT SHOWN TYP. 516 " COLL. PL CONN. TO COLUMN PER 2/s-816 T.O.S. LEVEL 2 2 TAB PL 1 2 " AND BOLTS PER 1B/s-522 1 1 1
