Steel studs sized per plan and schedule are bridged with S162-43 blocking installed at the splice location. Double horizontal flat strap splices span across the studs with a minimum of one number ten screw at each strap to stud intersection. Four number ten screws are fastened into the blocking on each side of the splice at equal spaces. Blocking and bridging are attached to the steel studs per sheet note 7/S6.1.
TYPICAL STUD SPACE PER PLAN STL STUD PER PLAN & SCHED DOUBLE FLAT STRAP BRIDGING SPLICE A HORIZ FLAT STRAP SPLICE S162-43 BLKG INSTALL AT SPLICE (4) #10 SCREWS MIN EA SIDE OF SPLICE INTO BLKG AT EQUAL SPACES MIN #10 SCREW AT EA STRAP TO STUD NOTE: ATTACH BLOCKING/BRIDGING TO STEEL STUDS PER . 1" TYP 1" TYP 7/S6.1
