A three-eighths-inch bent plate or angle is positioned below to provide closure for the concrete pour. The vertical leg of the bent plate is extended and bent to form the corner, with the edge plate terminating at the inside face of the column where less than two inches. Beams below are omitted for clarity. Three-sixteenths-inch welds are specified typical on both sides where applicable, joining the vertical leg to the horizontal leg. Additional reinforcing bars are required at concrete fill per sheet S703.
3/8" BENT PL OR ANGLE BELOW CONTRACTOR TO PROVIDE CLOSURE FOR CONCRETE POUR 1" MIN EXT EDGE BEAMS BELOW NOT SHOWN FOR CLARITY EXTEND VERTICAL LEG OF BENT PL AND BEND TO FORM CORNER 1/4" MAX 1" TYP WHERE <2", TERMINATE EDGE PLATE AT INSIDE FACE OF COLUMN 0 1 2 PER L TYP 3/16 TYP UON VERT LEG TO HORIZ LEG 1/8 LESS THAN 1/4" PL 3/16 3 BOTH SIDES TYP NOTE: 1. AT CONCRETE FILL, PROVIDE ADDITIONAL BARS PER DETAILS ON SHEET . S703
