Structural framing and reinforcement required around openings six to twenty-four inches wide in metal deck without concrete fill. An L1-1/2x1-1/2x3/16 angle is installed either above or below the metal deck before cutting the opening, with one-eighth-inch fillet welds applied typically at each flute. A bent plate sized per schedule connects perpendicularly to the wide flange beam supporting the deck assembly. Plug welds of three-quarters-inch diameter spaced at eighteen inches on center secure the bent plate through holes in the assembly. A minimum two-inch bearing is provided at the wide flange beam with a maximum eighteen-inch dimension 'A'.
METAL DECK SECTION A-A OPEN NOTE: APPLIES AT HOLES FROM 6" TO 24" WIDE IN METAL DECK WITHOUT CONCRETE L1-1/2x1-1/2x3/16, INSTALL ANGLE EITHER ABOVE OR BELOW DECK BEFORE CUTTING HOLE A A 12" MIN 'D' 'D' 12" MIN 'D' 1/8 1 1/2 TYP EA FLUTE BENT PL PER SCHED WF BM DECK AT PERP CONDITION MIN 2" 18" MAX 'A' MIN 5 1/2" 3/4"Ø 18"CC PLUG WELD THROUGH HOLE 1/8 2-12 TYP BENT PLATE 'A' THICKNESS TO 18" 1/4"
