Precast concrete panel details A and B show wall recesses reinforced with three number five continuous top and bottom bars along with number three ties spaced at twelve inches on center. Additional reinforcement is indicated on the panel elevation and detail one on sheet SD.3. Vertical reinforcement includes number five bars spaced at ten inches on center with a three foot zero inch lap splice. Dimensions and recess locations are referenced to the panel elevation.
