Structural · S-TKNEG

Typical Closure Plate at Overhang

Materials

Concrete Steel Metal (misc.)

Elements

Beams Floors / Slabs Decks Connections / Plates

Connections

Welded Connection Deck Attachment

About this detail

A closure plate is welded to the edge of a steel beam supporting concrete over a metal floor deck for interior conditions. The detail includes a sizing table relating overhang lengths under twelve inches to various plate thicknesses, with tack welds spaced at twenty-four inches on center maximum. Full depth web plates and coped steel beams connect via shear tabs as required, while exterior conditions refer to perimeter details on separate sheets. An optional three-eighths inch bent plate may be used for slab edges up to sixteen inches to eliminate kickers.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
