A non-bearing concrete masonry unit wall intersects a structural steel beam overhead with a vertical expansion joint. The top-of-wall bond beam stops short of the steel beam where interrupted, utilizing cut block infill and grip stay anchors provided at each course. A five-foot long bond beam is positioned in the first full course below the beam, and vertical reinforcement is added in each cell adjacent to the beam. Top braces are installed at alternate sides of the wall on each side of the beam per typical top brace details. A one-inch minimum clearance is maintained between the top of the wall and the underside of the structural slab.
T/WALL TYPICAL EXPANSION JOINT CUT BLOCK INFILL PROVIDE GRIP STAY ANCHOR AT EACH COURSE TYPICAL TOP OF WALL BOND BEAM STOPS SHORT OF BEAM WHERE INTERRUPTED 5'-0" LONG BOND BEAM IN FIRST FULL COURSE BELOW BEAM PROVIDE TOP BRACE AT ALTERNATE SIDES OF WALL ON EACH SIDE OF BEAM SEE TYPICAL TOP BRACE DETAILS 2'-0" ADD VERTICAL REINFORCEMENT IN EACH CELL ADJACENT TO BEAM WHEN TOP OF WALL BOND BEAM IS INTERRUPTED T/SLAB TYPICAL WALL REINFORCEMENT SEE TYPICAL CMU NON-BEARING WALL REINFORCEMENT SCHEDULE (-0", +1/2") 1" MIN CLR
