An HSS diagonal brace frames into the bottom flange of a wide-flange beam via a three-eighths-inch gusset plate. Three-eighths-inch stiffener plates are welded to each side of the beam web aligned with the connection. Fillet welds of one-quarter-inch size join the gusset plate and brace elements as typical.
1/4 5 1/4 5 TYP. 1/4 1/4 TYP. W BEAM SEE PLAN GUSSET PL 3/8" x AS REQ'D. HSS DIAGONAL BRACE, SEE PLAN STIFF PL 3/8" EACH SIDE OF WEB, SEE DETAIL B TOP BRACE AT BOTTOM OF W BEAM / 2 S5.40.1
