The drawing shows a plan view and a section view of cold-formed steel framing. The plan detail highlights the attachment condition for equipment, specifying no penetration in the backing where attachment occurs and extending backing into adjacent stud bays. The section view shows cold-formed steel studs with a backing track and provides load limits annotated as 350# max and 175# max.
Text on the drawing
3 STUD BAY BEYOND EDGE EXTEND BACKING ONE STUDS 3 PLAN DETAIL BACKING TRACK 2 SECTION EQUIPMENT 350# MAX 175# MAX OF ATTACHMENT. SEE NOTE #2 FOR PENETRATION NO PENETRATION IN BACKING WHERE ATTACHMENT OCCURS BACKING DETAILS AT PIPES
