Structural · S-TG3ZP

Ceiling Framing Transition Detail

Materials

Cold-formed Steel Timber / Wood Metal (misc.)

Elements

About this detail

Ceiling framing transitions are supported by three 5/8 inch by 18 gauge metal studs matching the ceiling framing spacing, tied to continuous 18 gauge end tracks with four number 8 screws at each end. Ceiling hangers are installed per detail D2/SE0-06, and ceiling framing members are sized per the frame ceiling schedule. A companion schedule provides maximum lengths for compression conduits ranging from 5 feet for 1/2 inch conduit up to 19 feet for 1 1/4 inch conduit.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
