Hollow structural section beams are sized per plan and feature miter-cut ends meeting at the building corner. The ends of the hollow structural sections are notched according to detail specifications. Three-sided fillet welds with a three-sixteenths inch size secure the connection typically along the top and bottom. Additional fabrication and installation information is referenced to separate detail callouts.
(3/16) (3) SIDES 3/16 (3/16) TYP. HSS BEAM PER PLAN (MITER CUT ENDS AT CORNER) HSS BEAM PER PLAN (MITER CUT ENDS AT CORNER) NOTCH END OF HSS BEAM PER DETAIL 1 - FOR REMAINDER OF INFORMATION REFER TO DETAIL 2 - (3/16) (T&B) 4 ROOF CANOPY BEAM CONN. AT BUILDING CORNER
