A 14-gauge metal Z-closure forms the vertical step down in a composite concrete fill and metal deck floor assembly. Continuous number 4 reinforcing bars run along the top and bottom of the step, supplemented by number 4 bars spaced at 12 inches on center. The assembly bears on a WT fill beam sized per plan beneath the metal deck and concrete fill. Dimensions and level markers coordinate the floor slab elevations across the step.
TOP OF FLOOR SLAB, SEE PLAN 14 GA Z-CLOSURE #4@12" #4 CONT T&B OF STEP WT FILL BEAM SEE PLAN FOR SIZE PLAN SEE SEE SCHED METAL DECK & CONC FILL SEE SCHED METAL DECK & CONC FILL 6"
