This structural plan detail shows a concrete wall corner reinforced with number four horizontal bars spaced at twelve inches on center each face and number five vertical bars spaced at nine inches on center each face. Two number five vertical bars run full height at the corner junction. A minimum two foot six inch lap splice is provided for the reinforcement. Typical pier reinforcement is referenced to panel elevations and details.
