A structural steel column is supported by a steel base plate set on one and one-half inches of non-shrink grout over a concrete footing. The column sits adjacent to a concrete blockout and a concrete slab on grade, with continuous footing reinforcement running uninterrupted through the spot footing. An exterior tilt-up concrete wall panel with a sandwich panel configuration bears near the foundation line.
13 S501 STEEL BASE PLATE (SEE SCHED) ON 1.1/2" NON- SHRINK GROUT CONCRETE BLOCKOUT 5/16 LINE OF CONTINUOUS FOOTING BEYOND RUN CONTINUOUS FTG REINF UNINTERUPTED THROUGH SPOT FTG CONCRETE SLAB ON GRADE, SEE PLAN CONCRETE FOOTING, SEE PLAN AND SCHED STEEL COLUMN, SEE PLAN AND SCHEDULE CONCRETE TILT-UP WALL PANEL, SEE PLAN AND ELEVATIONS EXTERIOR SLAB OR GRADE, SEE ARCH SANDWICH PANEL, SEE PLAN AND DETAIL 6/S201
