A concrete masonry unit wall is centered on a wide flange steel beam with a depth less than or equal to four feet six inches. A standard bond beam sits at the top of the masonry wall. An L6x3 1/2x5/16 by one foot zero inch or similar bent plate secures the assembly with three-sixteenths inch fillet welds. A typical top of wall gap is maintained, with a minimum two inch dimension provided. Additional bracing is connected to the underside of concrete on steel deck.
3" TYP TOW GAP SEE "TYP CMU BRACE TO UNDERSIDE OF CONC ON STL DECK" L6x3 1/2x5/16x1'-0" OR SIMILAR BENT PL AT "S2", TYP BOND BM L TO BM 3/16 3/16 3/16 3/16 1 1/2" WF BM W/ DEPTH LESS THAN OR EQUAL TO 4'-6" 2 7/8" 2" MIN 2" MIN, TYP
