A concrete slab edge and metal deck are supported by a structural steel edge beam. The assembly incorporates a twelve-gauge continuous steel edge form anchored with three-quarter-inch diameter field plug welds at twelve inches on center. Three-inch by fourteen-gauge Z clips are welded to the edge form and edge beam at twenty-four inches on center. Two continuous number four reinforcing bars run parallel to the edge form, while number three reinforcing bars at twelve inches on center reinforce the slab. A contractor note mandates checking the adequacy of the edge form and edge beam as sized per plan.
(2'-0" MAX) C #3@12" 3"x14 GA "Z" CLIPS WELDED TO EDGE FORM AND EDGE BEAM @ 24" "Z" CLIP NOTE: CONTRACTOR SHALL CHECK THE ADEQUACY OF EDGE FORM EDGE BEAM SEE PLAN EDGE FORM (2) #4 CONT 12 GA CONT EDGE FORM 3/4"Ø FIELD PLUG WELD @12" OC 4'-0" TYP (2'-0" MAX) SEE PLAN 2 2 2"
