A diagonal structural brace connects to a knife plate welded to the supporting steel frame. The knife plate shape is adjusted to suit the specific brace angle as shown on the drawings. The brace must be designed for the connection force indicated on sheet S-MB-0.04. The connection aligns with the top of the skybridge floor at elevation 106.10.
BRACE, SEE ELEVATION FOR CONNECTION DESIGN FORCE KNIFE PL ADJUST SHAPE TO SUIT BRACE ANGLE DESIGN BRACE FOR CONNECTION FORCE SHOWN IN SHEET S-MB-0.04 MB - T.O. SKYBRIDGE FLOOR 106.10
