A single concrete pile supports a thickened grade beam with embedded reinforcement detailed per plan. The grade beam features a thickened section at the pile location with four number seven reinforcing bars extending into the assembly. Grade beam reinforcement ties into the pile head with standard hooks for load transfer.
GRADE BEAM REINF PILE, SEE TYPICAL DETAIL TO GRADE BEAM BO GRADE BEAM THICKEN GRADE BEAM AS SHOWN AT PILE LOCATION, TYP 4#7 PILE (PC1A) SEE PLAN FOR LOCATION 4" 8" 1'-0" DEPTH GRADE BM 1'-0"
