A concrete tilt-up wall panel bears on a concrete footing with a 1-1/2-inch layer of non-shrink grout beneath the panel. An exterior slab on grade connects via a pourback strip containing #4 reinforcing bars spaced at 18 inches on center each way. A horizontal #4 reinforcing bar spans the full opening width within the slab edge, tied with #4 dowels measuring 3 feet 6 inches long at 18 inches on center.
CONCRETE SLAB ON GRADE, SEE PLAN EXTERIOR SLAB OR GRADE, SEE ARCH 1.1/2" NON-SHRINK GROUT #4 x 3'-6" DOWEL AT 18" O.C. 24" 18" #4 AT 18" O.C. EA WAY IN POURBACK STRIP CONCRETE TILT-UP WALL PANEL BEYOND #4 x OPENING WIDTH HORIZONTAL BAR CONCRETE FOOTING, SEE PLAN AND SCHED CONCRETE TILT-UP WALL PANEL, SEE PLAN AND ELEVATIONS AT OPENING 12" 2" CLEAR
