A wide-flange steel column bears on a base plate atop a three-inch layer of non-shrink grout and a concrete footing or pier. Buckling-restrained braces frame into gusset plates connected to the column web and base plate, with stiffener plates welded to both sides of the column web. ASTM F1554 Grade 105 threaded anchor rods with jam nuts secure the base plate, featuring plate washers and tack-welded nuts. Additional anchorage shear reinforcement consisting of three #3 top and bottom bars is centered on the embed plate and spaced vertically and horizontally below the plate, with standard hooks provided where full straight bars cannot fit. Side plates are positioned on each side and held vertical during welding, and shear studs are distributed per schedule.
WP 4"4" 3" CL BRB BUCKLING RESTRAINED BRACE, GUSSET PL AND CONNECTION TO COL AND BASE PL BY BRB SUPPLIER EMBED PL (te) PER SCHED SHEAR STUDS SEE SCHED AND APPLICABLE ANCHOR ROD LAYOUT ADDITIONAL ANCHORAGE SHEAR REINF CENTERED ON EMBED PLATE AND EQUALLY SPACED VERT AND HORIZ BELOW EMBED PL - SEE SCHED PROVIDE STD HOOK WHEN FULL STRAIGHT BAR CANNOT BE PLACED ON ACCOUNT OF FTG OR PIER DIMENSIONS (3) #3 TOP & BOT @ ANCHOR BOLT GROUP ASTM F1554 GRADE 105 THREADED ANCHOR RODS W/ JAM NUTS AT TOP SEE SPEC & STL COL SCHED FOR HOLE DIA IN BASE PL & BEARING PL SEE SCHED ON S-551 TACK WELD NUT TO ROD - TYP SEE PLAN T/FOOTING OR PIER SEE PLAN T/SLAB-ON-GRADE BASE PL "t"x"B"x"N" SEE COLUMN SCHED CONTR SHALL HOLD BASE PL RIGIDLY IN PLACE WHILE GROUTING WF COLUMN SEE STL COL SCHED SEE PLAN FOR ORIENTATION EQ EQ SHEAR STUDS SEE SCHED AND APPLICABLE ANCHOR ROD LAYOUT CONTR TO ENSURE AR PROJECTION HELD BELOW T/SLAB-ON-GRADE BASE PL "t"x"B"x"N" SEE COLUMN SCHED tw TYP PER SCHED SEE PLAN T/FOOTING OR PIER SEE PLAN T/SLAB-ON-GRADE SEE PLAN B/FOOTING TYP 3/4" SIDE PL (ts) EA SIDE PER SCHED CONTR TO ENSURE PLATE IS HELD VERTICAL DURING WELD EMBED PL (te) PER SCHED PLATE WASHER SEE SCHED ON S-551 SECTION AT RIGHT NOTE: FOUNDATION REINF NOT SHOWN FOR CLARITY CL BRB 2'-6" B/FOOTING SEE PLAN BUCKLING RESTRAINED BRACE, GUSSET PL AND CONNECTION TO COL AND BASE PL BY BRB SUPPLIER "t" GROUT 3" NON-SHRINK STIFFNER PL BOTH SIDES OF COLUMN WEB AS REQUIRED BY BUCKLING RESTRAINED BRACE MANUFACTURER LAP SPLICE CLASS "B"
