Cold-formed metal framing consists of 362S125-33 metal studs spaced at sixteen inches on center connecting to a partition wall. An L3x3x12 gauge angle clip is attached to each side of the metal stud with three number ten sheet metal screws at each leg. A continuous twenty gauge track and 1000S200-68 stud member form the suspended ceiling transition. Four number ten screws typically secure the framing connections, with number ten sheet metal screws spaced at twelve inches on center staggered typically.
