Suspended load attachment details for metal deck assemblies include configurations for both unfilled metal deck and concrete-filled metal deck. Unfilled metal deck details show threaded rods supported by a sixteen-gauge minimum washer, a plate, or an angle spanning the deck flutes, with maximum loads ranging from seventy-five to one hundred fifty pounds and a minimum two-foot-zero-inch spacing. Concrete-filled metal deck details show post-installed drilled anchors or inserts embedded into slabs with minimum thicknesses of two and one-half inches or three and three-quarters inches, accommodating maximum loads of three hundred and four hundred pounds respectively at a minimum two-foot-zero-inch spacing. A general note assigns the responsibility for connection design to the contractor unless otherwise noted.
