Concrete shear walls require specific reinforcement configurations at wall thickness transitions and wall openings. Vertical reinforcement steps at offsets up to six inches with a minimum one and a half inch and maximum four inch dimension, utilizing dowels matching the vertical reinforcement size and spacing above with a hooked vertical bar at the top of the wall where slabs occur. Wall openings feature U-bars matching adjacent vertical bar sizes and spacing, with vertical reinforcement extended to the edge of the opening and coupling beam extents reinforced per coupling beam details.
SLAB WHERE OCCURS HOOK VERT AT TOP OF WALL DOWEL TO MATCH VERT REINF SIZE & SPCG ABOVE NOTE 1 OFFSET NOTE 1 1 1/2" MIN 4" MAX OFFSET ≤6" 27 1/2" 6" 4 3/8" 24 5/8" SHEAR WALL LEVEL EXTEND REINF TO EDGE OF OPENING VERT REINF PER SW ELEVATIONS U-BARS TO MATCH ADJ VERT BARS SIZE & SPACING COUPING BEAM EXTENT, REINFORCE PER COUPLING BEAM DETAIL TYPICAL REINFORCEMENT AT WALL THICKNESS CHANGE 10 TYPICAL CONC WALL OPENING TRANSITION
