Typical L3x3x1/4 angle supports run parallel or perpendicular to the metal deck framing around a hollow structural section column with a maximum three-inch clearance "A". Deck support angles are supplied by the structural steel contractor or deck manufacturer depending on the specific detail notes. The support angles feature a one-eighth inch fillet weld typical. The deck support angle may be eliminated if dimension "A" is less than or equal to three inches and perpendicular to the deck span.
NOTES: 1. DECK SUPPORT ANGLES TO BE SUPPLIED BY STRUCTURAL STEEL CONTRACTOR 1/8 TYP TYPICAL L3X3X1/4 MAX TYP 3" "A" HSS COLUMN "A" NOTES: 1. DECK SUPPORT ANGLES AND CLOSURE PL TO BE SUPPLIED BY DECK MANUFACTURER. 2. DECK SUPPORT ANGLE MAY BE ELIMINATED IF "A" ≤3", "A" IS PERPENDICULAR TO DECK SPAN DETAIL B DETAIL A
