A structural steel beam supports a metal deck and concrete slab near a building grid line and exterior wall. A diagonal kicker angle is connected with a continuous angle and fillet welds, with studs attached for gravity connection. A continuous angle (L6x4x3/8) runs along the assembly, and structural steel angles (L3x3x1/4) are provided at each kicker. Clearances and gaps are detailed adjacent to the wall condition.
SEE DETAIL FOR CONDITION AT STEEL BEAM TO BEAM CONNECTION AND DETAIL WHEN BEAM DEPTH < 21" AND FOR INFORMATION NOT NOTED. GRID SEE ARCH 1"± GAP 2(1 MIN) 1 SEE ARCH GRAVITY CONNECTION (CLIP OR WELD) OF STUDS TO STRUCT BY SUPPLIER L6x4x3/8xCONT L3x3x1/4 AT EA KICKER KICKER, SEE 1/4 TYP 1/4 1/4 / (4 S610) / (1 S610) 1" CLR 6" ± 1/4 TYP / (1 S610) S610 5 AT SOLID WALL (WHERE OCCURS)
