A square steel base plate supports a hollow structural section column with a continuous fillet weld. Four anchor bolts secure the assembly at the corners with dimensions sized per the structural schedule. A grout hole is provided on the base plate with a size matching the anchor bolt hole diameter. Additional intersecting grid lines and clearances are referenced as shown on plan.
PLAN OR AWS MIN GROUT HOLE ON BASE PLATE - SIZE OF HOLE SAME AS ANCHOR BOLT HOLE SIZE 5/16 2" EQ EQ 2" LENGTH SEE SCHED 2" EQ EQ 2" WIDTH SEE SCHED 1" SEE PLAN SEE PLAN
