Reinforcing at a shear wall edge features horizontal hook bars matching the size and spacing of horizontal reinforcement with a zero-inch clearance. Hold-down bars are provided on each face per elevation and spaced at six inches on center. The panel edge includes a thirty-inch minimum lap and a three-quarters-inch maximum reveal, with reveals occurring as directed by architectural drawings. Additional number six vertical bars are placed at the corner. Concrete cover is one and three-quarters inches from the panel face and one inch at the opposite face, with panel thickness varying per elevations.
