Structural · S-SZCWZ

Structural Steel Column and Girt Connection

Materials

Steel

Elements

Beams Columns Connections / Plates Decks Doors

Connections

Beam-to-Column HSS Connection Welded Connection

About this detail

A steel column supports a steel beam and a continuous angle at the roof deck level, with a C150x19 channel framing at the column to support the continuous angle using typical complete joint penetration welds. Below, a hollow structural section 178x178 girt connects to the steel column framing per plan, supporting an exterior door assembly carried by an additional structural steel column referenced on another sheet.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
