A reinforced concrete column vertical bar offset and lap splice occurs where the offset exceeds three inches. Column vertical bars are offset to the inside of the bars above with a maximum one-to-six slope. For non-contact lap splices, the bar spacing must not exceed the lesser of six inches or one-fifth of the splice length. Ties or spirals are provided per the column schedule and note requirements.
#4 THRU #11 BARS CL DWL COL BAR SPLICE WHERE OFFSET EXCEEDS 3" TIES OR SPIRAL SEE DETAIL OF TYPE NOTED IN COL SCHED COL VERT OFFSET COL BARS TO INSIDE OF BARS ABOVE W/ 1:6 MAX SLOPE NOTE 1 NOTE 1 OFFSET 1" 1" . FOR NON-CONTACT LAP SPLICE, BAR SPACING NOT TO EXCEED LESSER OF 6" OR ONE-FIFTH OF SPLICE LENGTH
