A hollow structural section post is welded to a base plate anchored into a concrete footing or floor slab. The assembly is secured using two three-quarter-inch diameter F1554 Grade 36 anchor rods with heavy hex nuts or rod heads embedded in the concrete. A three-sixteenth-inch fillet weld connects the hollow structural section post to the base plate on all sides, with finished bearing surfaces provided at the column end and plate top. A one-inch minimum non-shrink grout layer is packed beneath the base plate, maintaining a one-and-a-half-inch minimum rod projection.
B/FTG T/FIN FLR OR FTG B/ROD OR ROD HEAD 3/16 ACROSS FLAT - ALL SIDES BASE PL SIZE PER COLUMN SCHED CL POST (2) 3/4"Ø F1554 GR 36 ANCHOR RODS HEAVY HEX NUT OR ROD HEAD HSS POST PLAN MIN 3" AISC RECOMMENDED BASE PL HOLE SIZE MIN AISC RECOMMENDED BASE PL WASHER SIZE PROVIDE FINISHED SURFACE AT COL END AND PLATE TOP FOR BEARING L W 2" MIN 2x ROD Ø, tPL PROJECTION 1 1/2" MIN ROD 8" GROUT MIN 1" NONSHRINK
