Wood post-to-beam framing connections utilize Simpson Strong-Tie column caps. Detail A incorporates an eccentric cap connecting a wood post to a wood beam sized per plan. Detail B incorporates a standard CC series column cap framing a wood post under a continuous wood beam. Detail C incorporates an ECCLL eccentric cap connecting a post and beam configuration. Detail D incorporates a CCT column cap connecting a wood post centered beneath intersecting wood beams. All wood post and beam sizes are determined per the architectural and structural plans.
