A concrete slab edge bears on a structural steel beam equipped with two rows of three-quarter-inch diameter by four-inch shear studs spaced at twelve inches on center. Continuous number four dowels with twelve-inch hooks extend one foot six inches past the steel beam at twelve inches on center. The vertical edge features a twenty-pound foam infill behind the concrete face. Horizontal number four bars at twelve inches on center reinforce the corners. A ledger for the lower slab is detailed separately.
4". TYP. VARIES. S.A.D 6" TYP. 1'-9" LEDGER FOR LOWER SLAB SEE 2/S5.13 #4 DOWELS CONT. W/ 12" HOOK AND 1'-6" PASS THE STEEL BEAM @ 12"O.C. TYP. #4 @ 12"OC. HORIZ. HOOK AT CORNERS 2 ROWS OF 3/4" DIA x4" STUDS @ 12"OC. PROVIDE 20# FOAM INFILL
